Beranda » Projector » Projector PANASONIC » Projector Panasonic PT-EX12K

Projector Panasonic PT-EX12K

Ditambahkan pada: 25 February 2015 / Kategori: Projector PANASONIC

klik full size

Kode	:	PT-EX12K
Berat	:	28 gram
Stok	:	Ready Stock
Dilihat	:	1.904 kali
Review	:	Belum ada review

Rp 206.000.000

Tentukan Pilihan!

Pesan melalui SMS? Klik SMS

Bayar di tempat? Klik COD

Bagikan informasi tentang Projector Panasonic PT-EX12K kepada teman atau kerabat Anda.

Deskripsi Projector Panasonic PT-EX12K

Model

Projector Panasonic PT-EX12K

Power supply

200-240 V AC, 50/60 Hz

100-240 V AC, 50/60 Hz

Power consumption

1,850 W (18 W with standby mode)

940 W (17 W with standby mode)

LCD panel

Panel size

46 mm (1.8 inches) diagonal (4:3 aspect ratio)

Display method

Transparent LCD panel (x 3, R/G/B)

Pixels

786,432 (1,024 x 768) x 3, total of 2,359,296 pixels

Pixel configuration

Stripe

Pure color control device

Lens

Optional

Lamp

380 W x 4, lamp replacement cycle(lamp power: Normal/Eco1, Eco2):2,000 hours/3,000 hours*¹

380 W x 2, lamp replacement cycle(lamp power: Normal/Eco1, Eco2):2,000 hours/3,000 hours*¹

Screen size (diagonal)

1.02–15.24 m (40–600 inches) (2.54–15.24 m [100–600 inches] with the ET-ELS03),4:3 aspect ratio

Brightness*²

16,000 lm (4-lamps, lamp power: Auto/Normal, Optional lens: ET-ELS03)

13,000 lm (2-lamps, lamp power: Auto/Normal, Optional lens: ET-ELS03)

Center-to-corner uniformity*²

90 %

Contrast*²

2,500:1(full on/full off, 4-lamps, lamp power: Auto)

4,000:1(full on/full off, 2-lamps, lamp power: Auto)

Resolution

1,024 x 768 pixels(Input signals that exceed this resolution will be converted to 1,024 x 768 pixels.)

Scanningfrequency

HDMI/DVI-D

Horizontal: 26–80 kHz, vertical: 23–85 Hz, dot clock: 162 MHz or lower

RGB (analog)

fH: 15–120 kHz, fV: 48–120 Hz, dot clock: 230 MHz or lower(Signals exceeding the dot clock rate of 165 MHz are downsampled.)

YPBPR (YCBCR)

fH: 15.75 kHz, fV: 60 Hz [480i (525i)]fH: 31.50 kHz, fV: 60 Hz [480p (525p)]fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]fH: 33.75 kHz, fV: 60 Hz [1035/60i]

fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]

fH: 28.13 kHz, fV: 50 Hz [1080/25sF]

fH: 27.00 kHz, fV: 48 Hz [1080/24sF]

fH: 33.75 kHz, fV: 60 Hz [1080/30sF]

fH: 56.25 kHz, fV: 50 Hz [1080/50p]

fH: 15.63 kHz, fV: 50 Hz [576i (625i)]fH: 31.25 kHz, fV: 50 Hz [576p (625p)]fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]

fH: 28.13 kHz, fV: 25 Hz [1080/25p]

fH: 27.00 kHz, fV: 24 Hz [1080/24p]

fH: 33.75 kHz, fV: 30 Hz [1080/30p]

fH: 67.50 kHz, fV: 60 Hz [1080/60p]

Video/S-Video

fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60],fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]

Optical axis shift

With the ET-ELW06: vertical ±39% from center of screen (powered)*³With the ET-ELW02/ELW04/ELS03/ELM01/ELT02/ELT03: vertical ±39%, horizontal ±10% from center of screen (powered)With the ET-ELS02: vertical ±50%, horizontal ±10% from center of screen (powered)With the ET-ELW03: the optical lens shift function cannot be used.

Keystone correction range

Vertical: Maximum ±40°, Horizontal: Maximum ±40°(with XGA signal input, for vertical/horizontal correction only, Optional lens: ET-ELS03)

Installation

Ceiling/floor, front/rear

Terminals

INPUT1

DVI-D IN

DVI-D 24-pin x 1(DVI 1.0 compliant, compatible with HDCP, compatible with single link only), 480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1035/60i, 1080/24p, 1080/24sF, 1080/25p, 1080/25sF, 1080/30p, 1080/30sF, 1080/60p, 1080/50p, VGA (640 x 480)–WUXGA (1,920 x 1,200)*⁴,compatible with non-interlaced signals only, dot clock: 25–162 MHz

HDMI IN

HDMI 19-pin x 1(compatible with HDCP, compatible with Deep Color), 480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1035/60i, 1080/24p, 1080/24sF, 1080/25p, 1080/25sF, 1080/30p, 1080/30sF, 1080/60p, 1080/50p, VGA (640 x 480)–WUXGA (1,920 x 1,200)*⁴,compatible with non-interlaced signals only, dot clock: 25–162 MHz

ANALOG IN

D-sub HD 15-pin (female) x 1 (RGB x 1)

INPUT2

RGB 5BNC IN/VIDEO IN

BNC x 5 (RGB/YPBPR/YCBCR x 1), shared with VIDEO IN (BNC x 1) (composite video)

S-VIDEO IN

Mini DIN 4-pin x 1 (S-Video)

INPUT3/INPUT4

Optional interface board slot, When the ET-MD16SD1 is installed,
	SERIAL IN (SDI IN 1/2): BNC x 2 (SD-SDI signal/single link HD-SDI signal)
		SD-SDI signal (YCBCR 4:2:2 10-BIT): 480i, 576i (SMPTE 259M-C compliant)
		Single-link HD-SDI signal (YPBPR 4:2:2 10-BIT): 720/50p, 720/60p, 1035/60i, 1080/50i, 1080/60i, 1080/25p, 1080/25sF, 1080/24p, 1080/24sF, 1080/30p, 1080/30sF (SMPTE 292M compliant)
	SERIAL OUT (SDI OUT): BNC x 1 (active through)

SERIAL IN

D-sub 9-pin (male) x 1for external control

D-sub 9-pin (female) x 1for external control

SERIAL OUT

D-sub 9-pin (male) x 1 for link control

REMOTE IN

M3 Jack x 1 (for wired remote control)

LAN

RJ-45 x 1 (for network connection, 100Base-TX/10Base-T,compliant with PJLink™ [class1])

USB

USB type-B (USB connector) x 1*⁵

Cabinet materials

Molded plastic

Dimensions (W x H x D)

650 x 349 x 815 mm(25.6” x 13.7” x 32.1”)(with legs at shortest position, optional lens not included)

538.5 x 268 x 757 mm(21.2” x 10.6” x 29.8”)(with legs at shortest position, optional lens not included)

Weight

Approximately 46.5 kg (102.5 lbs)(optional lens not included)

Approximately 28 kg (61.7 lbs)(optional lens not included)

Noise level

51 dB (lamp power: Normal/Eco2),48 dB (lamp power: Eco1)

42 dB (lamp power: Normal/Eco2),39 dB (lamp power: Eco1)

Operating temperature

5°C- 40°C [41°F-104°F] (less than 1,800 m [5,906 ft] above sea level),5°C- 30°C [41°F-86°F] (between 1,800 m and 2,700 m [5,906 ft to 8,858 ft] above sea level)

0°C- 40°C [32°F-104°F] (less than 1,400 m [4,593 ft] above sea level),0°C- 30°C [32°F-86°F] (between 1,400 m and 2,700 m [4,593 ft to 8,858 ft] above sea level)

Operating humidity

20–80 % (no condensation)

Supplied accessories

Power cord x 1 (x 2 for PT-EX16KE/EX12KE), power cord holder/power cord cover x 1set, wireless/wired remote control unit, batteries (AAA/R03/LR03 type x 2), VGA cable x 1,software CD-ROM (Logo Transfer Software, Multi Projector Monitoring & Control Software, Real Color Manager Pro.), lens attachment x 1set, lens lock lever fixing bracket x 1set, lightshielding plate x 3set, spacer x 1set, cable tie x 3
