Vivid Clarity in Bright Medium-Sized Conference Rooms
4,000 lumens of high brightness enable comfortable lights-on presentations to promote discussion, collaboration, and note-taking in larger meeting rooms with bright lights accommodating up to 40 participants. The high luminance lets even participants seated furthermost clearly see the slides and boosts picture quality with vibrant color for pictures and videos as well as crisp text and fine details.
All Specifications
Display
Native Resolution : WXGA(1280 x 800)
Resolution Support : VGA(640 x 480) to WUXGA_RB(1920 x 1200)
Brightness (ANSI lumens) : 4,000 Lumens
Contrast Ratio (FOFO) : 20,000:1
Display Color : 30 Bits (1,07 billion colors)
Native Aspect Ratio : Native 16:10 (5 aspect ratio selectable)
Light Source Wattage : 240W
Light Source life : Normal 4000 hours
Eco 8000 hours
SmartEco 8000 hours
Lampsave 15000 hours
Optical
Lens : F=2.59~2.87, f=16.88~21.88
Keystone Adjustment : 2D keystone, Vertical ± 30 & Horizontal ± 20 degrees, Auto Vertical keystone
Projection Offset** : 110%±2.5% (Full-Height)
Clear Image Size (Diagonal) : 60″~180″
Horizontal Frequency : 15K-102KHz
Vertical Scan Rate : 23~120Hz
Audi0
Speaker : 10W x1
Interface
Monitor out (D-sub 15pin) : 1
HDMI : 2 (1.4a one shared w/ MHL)
USB Type A : 2 (one for Wireless dongle, one for USB reader, Power supply, 5V,1A)
USB Type Mini B : 1 (Download & Page up/down )
Audio in (3.5mm Mini Jack) : 1
Audio out (3.5mm Mini Jack) : 1
IR Receiver : 2(Front/Top)
Compatibility
HDTV Compatibility : 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility : NTSC, PAL, SECAM
Environment
Power Supply : AC 100 to 240 V, 50/60 Hz
Typical Power Consumption : 320W (Normal)
Standby Power Consumption : <0.5W
Network Stand-by Power Consumption : <2W
Acoustic Noise (Typ./Eco.) : 33/29 dBA (Normal/Eco mode)
Operating Temperature : 0 ~ 40oC
Dimension and Weight
Dimensions (W x H x D)(mm) : 296 x 120x 221 mm
Net Weight (Kg/ lbs ) : 2.5kg
Accessories (Standard)
Carton : Brown carton
Remote Control w/ Battery : x 1 (RCE013)
Power Cord (by region) : x 1 (1.8m)
User Manual CD : x 1 (24L)
Quick Start Guide : x 1 (18L)
Warranty Card (by region) : x 1
VGA(D-sub 15pin) Cable : x 1 (1.5m)
Accessories (Optional)
Universal Ceiling Mount : Yes
QCast Mirror dongle : Yes
Wireless USB Dongle : Yes (WDRT8192 Dongle)
OSD : OSD Language
Arabic/Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/Japanese/ Korean/
Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/TraditionalChinese/Vietnamese /Farsi
(30 Languages)
*Lamp in this product contains mercury.
To dispose of the product or used lamps, consult your local environment authorities for regulations or see www.lamprecycle.org.
*Lamp life results will vary depending on environmental conditions and usage. Actual product’s features and specifications are subject to change without notice.
**Offset is calucated by full screen height.
