Projector Panasonic PT-VX510EA

Ditambahkan pada: 20 February 2015 / Kategori: Projector PANASONIC

Bagikan informasi tentang Projector Panasonic PT-VX510EA kepada teman atau kerabat Anda.

Deskripsi Projector Panasonic PT-VX510EA

Spesifikasi Panasonic PT-VX510EA

Power Supply		100-240V AC, 50 / 60 Hz
Power Consumption		365W (0.3W when standby mode set to Eco*¹, 11.5W when standby mode set to Network.)
LCD Panel	Panel Size	16 mm (0.63 in) diagonal (4:3 aspect ratio)
	Display Method	Transparent LCD panel (x 3, R / G / B)
	Pixels	786,432 (1,024 x 768) x 3, total of 2,359,296 pixels
Lens		1.6x manual zoom (throw ratio: 1.18-1.90:1), manual focus, F 1.60-2.12, f 15.28-24.62 mm
Lamp		280 W x 1, lamp replacement cycle (lamp power: Normal / Eco): 2,500 hours / 4,000 hours*²
Screen Size (diagonal)		0.76-7.62 m (30-300 in), 4:3 aspect ratio
Brightness*³		5,500lm (lamp power: Normal)
Centre-to-Corner Uniformity*³		85%
Contrast*³		4,000:1 (full on / full off, lamp power: Normal, Iris: On)
Resolution		1,024 x 768 pixels*⁵
Scanning Frequency	HDMI	fH: 25-80 kHz, fV: 50-85 Hz, dot clock: 162 MHz or lower
	RGB (Analogue)	fH: 15-100 kHz, fV: 50-100 Hz, dot clock: 140 MHz or lower (Signals exceeding the dot clock rate of 140 MHz are downsampled.)
	YPBPR (YCBCR)	fH: 15.75 kHz, fV: 60 Hz [480i (525i)] fH: 15.63 kHz, fV: 50 Hz [576i (625i)] fH: 31.50 kHz, fV: 60 Hz [480p (525p)] fH: 31.25 kHz, fV: 50 Hz [576p (625p)] fH: 45.00 kHz, fV: 60 Hz [720 (750) / 60p] fH: 37.50 kHz, fV: 50 Hz [720 (750) / 50p] fH: 33.75 kHz, fV: 60 Hz [1125 (1035) / 60i] fH: 33.75 kHz, fV: 60 Hz [1080 (1125) / 60i] fH: 28.13 kHz, fV: 50 Hz [1080 (1125) / 50i]
	Video / S-Video	fH: 15.75 kHz, fV: 60 Hz [NTSC / NTSC4.43 / PAL-M / PAL60], fH: 15.63 kHz, fV: 50 Hz [PAL / PAL-N / SECAM]
Optical Axis Shift		Vertical: +40%
Keystone Correction Range		Vertical: ±30° (±20° when Real-Time Keystone)
Installation		Ceiling / floor, Front / rear
Terminals	HDMI IN	HDMI 19-pin x 1 (Deep Colour, compatible with HDCP) 480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p, VGA (640 x 480)-WUXGA (1,920 x 1,200), *⁶ audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz)
	COMPUTER IN 1	D-sub HD 15-pin (female) x 1 (RGB / YPBPR / YCBCR x 1)
	COMPUTER IN 2 / MONITOR OUT	D-sub HD 15-pin (female) x 1 (RGB x 1), (input / output selectable using on-screen menu) (When Monitor Out is selected, the COMPUTER IN 1 signal is output.)
	VIDEO IN	Pin jack x 1 (Composite VIDEO)
	S-VIDEO IN	Mini DIN 4-pin x 1 (S-VIDEO)
	AUDIO IN	Pin jack x 2 (L/R x 1) for VIDEO / S-VIDEO input
	COMPUTER AUDIO IN 1	M3 x 1 (L-R x 1)
	COMPUTER AUDIO IN 2 (MIC IN)	M3 x 1 (L-R x 1) for audio input or for microphone connection (variable)
	AUDIO OUT	M3 x 1 (L-R x 1) for output (variable)
	SERIAL IN	D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
	LAN	RJ-45 x 1 (for network connection, 10Base-T / 100Base-TX, compliant with PJLink™ (class 1))
Built-in Speaker		4 cm round shape x 1, output power: 10.0 W (monaural)
Noise Level		38 dB (lamp power: Normal), 31 dB (lamp power: Eco)
Cabinet Materials		Molded plastic
Dimensions (W x H x D)		379 x 107 x 305 mm (14.9 x 4.2 x 12.0 in) (with legs at shortest position, not including protruding parts)
Weight		Approximately 4.8 kg (10.6 lbs)
Operating Temperature		0°C – 40°C [32°F – 104°F]*⁷ (less than 1,200 m [3,937 ft] above sea level, Fan control: OFF), 0°C – 30°C [32°F – 86°F] (between 1,200 m and 2,000 m [3,937 ft and 6,562 ft] above sea level, Fan control: ON1), 0°C – 30°C [32°F – 86°F] (between 2,000 m and 2,700 m [6,562 ft and 8,858 ft] above sea level, Fan control: ON2)
Operating Humidity		20% – 80% (no condensation)
Supplied Accessories		Power cord x 1*⁸, power cord holder x 1, wireless remote control unit, batteries (AAA / R03 / LR03 type x 2), carrying bag x 1, computer cable (1.8 m, for VGA) x 1 Software CD-ROM (Logo Transfer Software, Multi Projector Monitoring & Control Software)
