Projector Panasonic PT-AR100

Panasonic PT-AR100

Home Theater Projector
– Full-HD LCD projection
– 2,800 lemens of brightness
– 50,000:1 contrast ratio
– 7 picture modes
– Simple installation

Spesifikasi

PANEL

• Panel type : LCD
• Panel size – Diagonal (mm) : 18.7 (16:9 aspect ratio)
• Display method : Transparent LCD Panel (x 3, R / G / B)
• Drive method : Active Matrix
• Pixels : 2,073,600 (1920 x 1080) x 3
  Total of 6,220,800

DISPLAY

• Lens :  Manual Zoom 1.33 – 2.69:1
  Manual Focus Lenses F 2.0 – 3.4, f 21.5 – 43.0 mm
• Throw ratio : 1.16 – 18.08
• Lamp (W) : 280 UHM Lamp
• Screen size – Diagonal (m) : 1.02 – 7.62
• Colours : Full Colour (1,073,741,824 colours)
• Brightness (lumens) : 2800
• Center-to-corner Uniformity (%) : 85
• Contrast ratio : 50,000:1
• Resolution (pixels) : 1920 × 1080
• Video / S-Video :    f H : 15.75 kHz, f V : 60 Hz [NTSC / NTSC4.43 / PAL-M / PAL60]
  f H : 15.63 kHz, f V : 50 Hz [PAL / PAL-N / SECAM]

OPTICAL OFFSET

• Optical axis shift : Vertical: ±65%, Horizontal: ±26%
• Keystone correction range : Vertical: Approx. ±30°
• Installation : Ceiling / Desk, Front / Rear

TERMINALS

• HDMI IN : HDMI connector × 2
  HDMI™ (Deep Colour, x.v.Colour™, CEC)
  HDCP compliant, supports HDAVI Control Version 5
• Computer 1 IN  : D-sub HD 15-pin × 1 (RGB / YP B P R × 1)
• Computer 2 IN : COMPONENT IN RCA pin × 3 (YPBPR / YCBCR)

Trigger IN / OUT

• 3D Shutter OUT : TRIGGER IN / TRIGGER OUT
  M3 × 2, 12 V, Max. 100 mA
  (input / output selectable using on-screen menu)
• Video IN : RCA pin x 1
• S-Video IN : Mini DIN 4-pin x 1
• Serial IN : D-sub 9-pin × 1 for external control (RS-232C compliant)
• Optional : Replacement Lamp Unit ET-LAA110
  Ceiling Mount Bracket ET-PKA110H (for high ceilings)
  Ceiling Mount Bracket ET-PKA110S (for low ceilings)

POWER

• Power supply (V AC) : 100 – 240 AC, 50 / 60 Hz
• Power consumption (W) : 350 – 0.08 Standby Mode
• Power cord length (m) : 3

GENERAL

• Cabinet materials : Moulded Plastic
• Dimensions – W x H x D (mm) : 48 x 138 x 28.3
• Weight (kg) : 8.6
• Operating noise (dB) : 29 (Lamp Power: Eco)
• Operating temperature (o C) : 0 – 40
• Operating humidity (%) : 20 – 80 (no condensation)

REMOTE CONTROL UNIT

• Power supply (V) : 3 DC (R6 / AA type battery) × 2
• Operation range (m) : Approx. 7 (when operated from directly in front of the signal receptor)
• Weight – Including batteries (g) : Approx. 125

ACCESSORIES

• Standard : Power Cord x 1 (× 2 for PT-AR100EA)
• Wireless : Remote Control Unit
