Projector Hitachi CP-X3041WN

Projector Hitachi CP-X3041WN

Hitachi CP-X3041WN LCD ini adalah  proyektor yang menggabungkan kejelasan gambar, nilai kualitas tinggi, dan kehandalan. Warna teks yang lebih cerah dan hidup dan juga gambar grafis yang benar-benr tajam.  Untuk kenyamanan instalasi yang lebih besar, CP-X3041WN memiliki fungsi kloning yang memungkinkan Anda untuk menyalin pengaturan konfigurasi dari satu proyektor kepada orang lain dari model yang sama melalui memori USB. CP-X3041WN juga termasuk iOS aplikasi Projector Cepat Connection  yang menawarkan pilihan kontrol sederhana termasuk mengirimkan foto dan dokumen file dan isi situs web ke proyektor dan  menggabungkan kinerja gambar yang optimal dengan penghematan energi maksimum.

Spesifikasi

Display

• Projection Technology : 3LCD, 3 chip technology
• Resolution : XGA – 1024 x 768
• White Light Output : 3,200 ANSI lumens
• Color Light Output : 3,200 ANSI lumens
• Colors : 16.7 million colors
• Aspect Ratio : Native 4:3 and 16:9 / 16:10 compatible
• Contrast Ratio : 10,000 : 1 (using active IRIS)
  Throw Ratio (distance : width) : 1.5 – 1.8 : 1
• Focus Distance : 32″ – 425″
• Display Size : 30″ – 300″

Lens & Operation

• Lens : F = 1.9 – 2.3, f = 19 – 23 mm, x 1.2 manual zoom
• Lamp Wattage : 225W
• Expected Lamp Life* : Approximately 5,000 hours (standard mode) 10,000 hours (Eco-2 mode)
• Expected Filter Life** : Approximately 5,000 hours
• Speaker Output : 16W
• Keystone : H and V: +/- 30º

Compatibility

• Computer : VGA, SVGA, XGA, WXGA/WXGA+/SXGA/SXGA+/UXGA (compressed), MAC 16″
• H-Sync : 15 kHz – 106 kHz
• V-Sync : 50 Hz – 120 Hz
• Composite Video : NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
• Component Video : 480i, 480p, 576i, 720p, 1080i, 1080p
• HDMI : 480i, 480p, 576i, 720p, 1080i, 1080p,
  Computer signal TMDS Clock 27 MHz – 150 MHz

Connectors

• Digital Input : HDMI x 2 (HDCP compliant)
• Computer Input 1 : 15-pin mini D-sub x 1
• Computer Input 2 : 15-pin mini D-sub x 1 (shared with Monitor out)
• Computer Monitor Output : 15-pin mini D-sub x 1 (shared with Computer in 2)
• Video Input
  S-Video : N/A
  Composite Video : RCA jack x 1 : Component Video, 15-pin mini D-sub x2 (shared with computer in 1, in 2/Monitor out)
• Audio Input : 3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1, MIC-in 3.5 mm mini jack x 1
• Audio Output : 3.5mm stereo mini jack x 1
• Network LAN Wired : RJ-45 port
• Network LAN Wireless : USB-A, IEEE802.11 b/g/n – optional wireless adapter required
• USB : Type A x 2 (PC-less presentation, wireless adapter), Type B x 1 (USB display or mouse control)

Control Terminals : 9-pin D-sub x 1 (RS-232 control)

• Ratings & Warranty
• Power Supply : AC100-120V / AC220-240V, 50/60Hz
• Power Consumption : 330W
• Operating Temperature : 41ºF – 95ºF (5ºC – 35ºC)
• Dimensions (W x D x H) : 12.6″ x 9.7″ x 3.4″ (excluding protruding parts)
• Weight : Approximately 6.8 lbs.
• Approvals : UL 60950-1 / cUL FCC Part 15 subpart B class B
• Warranty : 3 year limited parts and labor, Extended Service Contract available (additional cost)

Accessories and Lenses

• Supplied  Accessories : Remote control, power cord, computer
  cable, 2 AA batteries, lens cover, adapter
  cover, security label,  application CD,
  user’s manual CD, user’s manual
• Optional Accessories : USBWL11N USB wireless adapter,
  MS-1 wired and MS-1WL wireless
  multifunction switchers, TB-1 wireless
  pen tablet
• Optional Lenses : NA
• Replacement Parts
  Lamp : DT01481 with filter
  Remote Control : HL03031
  Filter : UX3884
